Viair 100C Chrome Air Compressor With Omega Bracket

Viair 100C Chrome Air Compressor With Omega Bracket - Image 2

Viair 100C Chrome Air Compressor With Omega Bracket

Original price was: $142.95.Current price is: $99.99.

SKU: AG9YB 935677120196778 Categories: COMPONENTS, COMPRESSORS & AIR SOURCE UNITS Tags: 10016, 12 Volt, Air Compressors, Cn:prop65-lead, Leasable, Light Duty, Spo-default, Spo-disabled, Viair, Viair 10016

Free Shipping over $25
Fast & reliable delivery options
Enjoy top quality items for less
Multiple safe payment methods

Description
Reviews (0)

Description

THIS COMPRESSOR IS STRAPPED.

Looking for an air compressor that won’t cost you a ton? Meet the Viair 100C Silver Compressor with Omega-Style Bracket! Perfect for light pneumatic applications, this compressor is no-frills but all thrills. With the included Omega mount, you can install it in a jiffy and show off its chromed-out hosing and endplates that give it a polished professional look. And the best part? The insulated wiring is already pre-installed, so you can start using it right away.

**To ensure the longevity and proper function of the air compressor, it is recommended to install it in a sheltered area, away from exposure to weather conditions and the elements.**

Permanent Magnetic Motor
Oil-Less Design
High-Performance PTFE Piston Ring
Stainless Steel Valves
Gearless Direct Drive Motor
Anodized Aluminum Alloy Cylinder
Automatic Reset Thermal Overload Protector
Omega Style Mounting Bracket
Insulated Wiring with Connectors

Performance Data & Fill Rates

PSI	CFM	A	BAR	LPM	A
0	1.27	9	0	36.0	9
10	0.90	10	1.0	25.0	10
20	0.85	11	2.0	22.5	11
30	0.79	11	3.0	21.0	12
40	0.76	12	4.0	20.0	13
50	0.72	12	5.0	18.3	12
60	0.71	13	6.0	17.0	12
70	0.67	13	7.0	15.0	12
80	0.64	12	8.0	13.7	12
90	0.59	12	9.0	12.3	12
100	0.55	12
110	0.52	12
120	0.48	12
130	0.45	12

* Supply Voltage: 13.8 Volts

0.5 GALLON TANK	FILL RATE
0 to 105 PSI	50 sec. (± 05 sec.)
85 to 105 PSI	10 sec. (± 03 sec.)
0 to 120 PSI	1 min. 00 sec. (± 05 sec.)
90 to 120 PSI	17 sec. (± 03 sec.)
1.0 GALLON TANK	FILL RATE
0 to 105 PSI	1 min. 40 sec. (± 10 sec.)
85 to 105 PSI	25 sec. (± 05 sec.)
0 to 120 PSI	2 min. 00 sec. (± 10 sec.)
90 to 120 PSI	35 sec. (± 05 sec.)

* Supply Voltage: 13.8 Volts

Diagrams & Manuals

Viair 100C With Omega Bracket Manual
Viair 100C With Omega Bracket Wiring Diagram
Viair 100C With Omega Bracket Dimensional Drawing

Includes

Viair 100c 12 Volt Air Compressor
Omega Style Bracket
Mounting Hardware

Specifications

Part Number: AC-100
Manufacturers Part Number: 10016
Voltage: 12 Volts DC
Max Amperage: 14 Amps
Maximum Duty Cycle: 15%
Maximum Pressure: 130 PSI
Max Tank Size: 1 Gallon
CFM: 1.27 CFM
Length: 6.0″ (161.3 mm)
Width: 3.5″ (83.82 mm)
Height: 5.3″ (124.46 mm)
Weight: 3.50 lb (1.59 Kg)
